CNWINNEX Explosion-Proof Combined Air Handling Unit | Modular Explosion-Proof AHU for Hazardous Areas
CNWINNEX Explosion-Proof Combined Air Handling Unit | Modular Explosion-Proof AHU for Hazardous Areas
The explosion-proof combined air handling unit is the key air treatment equipment in HVAC systems. It is mainly designed for industrial sites where explosive atmospheres formed by flammable gases or vapours of Group ⅡA, ⅡB, ⅡC and temperature classes T1~T4 mixed with air may exist. The unit is designed and manufactured in strict compliance with ATEX Directive 2014/34/EU and the EN 60079 series explosion protection standards. Explosion-proof marking: Ex db mb IIC T4 Gb, suitable for Zone 1 and Zone 2 explosive hazardous areas. All electrical components and operating circuits are fully treated for explosion protection. Complete explosion-proof technical documentation is supplied to support HSE review and site acceptance for chemical, oil & gas and pharmaceutical projects worldwide.
The unit adopts a modular design with single or multiple functional sections, including fresh & return air mixing section, pre and medium efficiency filter section, fresh air & exhaust section, intermediate (maintenance) section, secondary return air section, cooling coil section, heating section, water spray section, silencer section, humidification section, flow equalizing section, supply/return fan section and air outlet section. Sections can be selected and combined according to project requirements. The unit offers flexible configuration and easy disassembly for wide applications across industries. Custom non-standard design and manufacturing are available upon request.
Key Product Features
● Low investment with high performance: Lower upfront capital cost while delivering excellent heat transfer and ventilation performance
● Low power consumption and low running cost: Electricity consumption of only about 1 kWh per hour. For the same installation area, the evaporative energy-saving air conditioner consumes about 1/8 of the power of central air conditioning
● Long air delivery distance with large airflow: Air volume reaches above 18,000 m³/h, satisfying ventilation requirements of large-area workshops
● Excellent air purification: Integrated ventilation, air exchange, purification and odour removal. It exhausts odorous, dusty and stuffy indoor air and brings in fresh outdoor air. Filtration efficiency for dust particles larger than 1μm exceeds 80%
● Remarkable cooling performance: Achieves temperature drop of 4℃ to 10℃ with rapid cooling response
Functional Section Introduction
● Pre-filter section: Uses non-woven panel pre-filter to preliminarily capture large particles in fresh air, meeting internal hygiene requirements and reducing the load on medium filter section.
● Medium filter section: Uses non-woven bag filter to remove secondary dust generated through ducts and the unit, further reducing filter load and improving supply air cleanliness.
● Fan section: Adopts low-noise centrifugal fan with low sound level and high static pressure. Variable frequency control is available upon customer request.
● Cooling coil section: Cooling coil face velocity ≤2.5 m/s, constructed with hydrophilic flat fins, delivering good heat transfer performance while resisting dust accumulation and bacterial growth, without water carry-over.
● Heating section: Hot water heating, steam heating or electric heating available. Electric heating adopts smooth stainless steel tubes without fins, featuring corrosion resistance, low dust accumulation and easy cleaning.
● Humidification section: Dry steam humidification is available, ensuring no residual water inside the humidifier after shutdown to eliminate bacterial growth.
● Sterilization: UV or ozone generator can be selected to sterilize the unit and destroy the living environment of bacteria, ensuring supply air hygiene.
Typical Applications
Chemical workshops, oil & gas production plants, hazardous material workshops, pharmaceutical explosion-proof workshops, energy storage plants, paint booths and other Zone 1 / Zone 2 hazardous areas containing Group ⅡA / ⅡB / ⅡC, T1~T4 explosive gas mixtures.
